frame design
- tubeset Toray T1000
- fork Columbus Futura
- handmade built tube to tube
- bottom bracket T47 68mm
- headset bearings 52 mm - 52 mm
- thru axle front 100*12mm / rear 142*12mm
- cockpit internal cable routing disc brake line / optional external
- frame internal cable routing disc brake line
- compatible with chain rings 2 x ..
- compatible with Di2, AXS / optional mechanical
- seatpost diameter 27.2 mm
- integrated Casati seatpost lock / optional seatpost collar
- front derailleur mount stationary
- disc rotor size rear 140 mm or 160 mm / front 160 mm
- weight frame 950g (size 54cm), fork 430g
- frame size / geometry made to measure
- max tire size 32 mm
warranty
2 years Casati frame/fork
components manufacturer's warranty terms and conditions
color design
- custom
see gallery for color / design ideas
groupset
- PROGETTO Ultegra
assembled with Shimano Ultegra Di2 12s - PROGETTO 105
assembled with Shimano 105 Di2 12s - PROGETTO Force
assembled with Sram Force AXS 12s
chain
- lubricated
- optional waxed
easier cleaning. cleaner working when having a mechanical on road, no oil pollution
wheelset
- Fulcrum Soniq AL 23
tires
- Pirelli P Zero Road 28 mm (optional 30 mm, 32 mm)
- inner tube Pirelli Smartube
feels like tubeless, but no mess when changing tires on road
saddle
- Prologo Zero
- Prologo Kappa
seatpost
- Deda Zero 100 setback 0 mm / 12 mm
handlebar
- cbTec one piece stem / handlebar
- optional Deda Superbox / Deda Superzero Aluminum
headset bearings
- steel Deda DCR
- optional Enduro inox
components custom setup possible
groupset, tires, saddle, 2 piece Deda stem and handlebar
sizes / geometry
exclusively made to measure
see how to plan your custom geometry
we guide you through the custom made process
lead time 8 weeks
